Texas Instruments, IC Digital Isolator, Part #: ISO7721FDWVR

IC Digital Isolator

• OEM: Texas Instruments

• Part #: ISO7721FDWVR
• Description: DGTL ISO 5000VRMS 2CH GP 8SOIC

• Detailed Description: General Purpose Digital Isolator 5000Vrms 2 Channel 100Mbps 85kV/µs CMTI 8-SOIC (0.295", 7.50mm Width)

• Category: Isolators - Digital Isolators
• Technology: Capacitive Coupling
• Type: General Purpose
• Number of Channels: 2
• Inputs - Side 1/Side 2: 1/1
• Channel Type: Unidirectional
• Voltage - Isolation: 5000Vrms
• Data Rate: 100Mbps
• Propagation Delay tpLH/tpHL (Max): 16ns, 16ns
• Pulse Width Distortion (Max): 4.9ns
• Rise/Fall Time (Typ): 1.8ns, 1.9ns
• Mounting Type: Surface Mount

TEX:ISO7721FDWVR
